Model

Smart S8001

CPU

Default Configuration

Onboard Intel® Celeron® Processor J1900 2.0GHz, up to 2.41GHz, 2M Cache, 64 Bit, Quad-Core

Memory

Default Configuration

4GB DDR3L SODIMM (1×SODIMM), Max. 8GB

Extensions (optional)

Default Configuration

1×500GB (With 24×7 operation)

Option

CF, DOM, HDD (2.5"), SSD

Storage

Option

8×RS-232/485 (terminal, 2.5KV2.5 KV isolation / 2KV surge protection);
4 or 6×10/100/1000M;
1×PCIe expansion slot

I/O Interface

Serial Port (DB9)

Standard: 1 (COM1: DB9, RS-232/422/485, COM2: internal, retention)

USB

Standard: 4×USB 2.0 (rear);
1×USB 3.0 (internal), Internal USB Key Port

SATA

2×SATA 2.0

LAN

6×10/100/1000M

B Code

Option

GPIO

16-Bit

Audio

Build-in, Optional external

K&M Port

USB

Display

Video Port

1×VGA, 1×HDMI

Video Memory

On board, DVMT

Monitoring

Watchdog

0~255 Sec

Power

Default Configuration

12VDC Input(3 Port terminal), with 100～240VAC power adapter

Mechanical Specifications

Cooling

Fanless

Construction

Aluminum & Steel

Mounting

Desktop, wallmount

Dimensions (W×H×D)

200mm×65mm×255mm (Standard)
200mm×95mm×255mm (Optional extensions)

Weight

3kg (w/o power adapter)

Environmental

Operating Temperature

-10～55℃

Storage Temperature

-30～70℃

Relative Humidity

5～95% (non-condensing)

Certification

FCC、CE
